Blood-Glucose Testing: AI and FT-IR Claim Improved Accuracy to 98.8%
A research team is claiming significantly enhanced accuracy of non-invasive blood-glucose testing by upgrading Fourier transform infrared spectroscopy (FT-IR) with multiple-reflections, quantum cascade lasers, two-dimensional correlation spectroscopy, and machine learning. The study, published in Spectrochimica Acta Part A, reports achieving a record-breaking 98.8% accuracy, surpassing previous benchmarks for non-invasive glucose detection.
Woman testing glucose level with traditional glucose monitor © Andrey Popov - stock.adobe.com
A study led by Liying Song, Zhiqiang Han, Po-Wan Shum, and Woon-Ming Lau has successfully transformed the accuracy of non-invasive blood-glucose testing. Conducted at Linyi University and the University of Science and Technology Beijing, the research integrates multiple technological advancements to overcome limitations in traditional Fourier transform-infrared (FT-IR)-based glucose testing (2).
Blood-Glucose Testing
Current non-invasive glucose testing methods rely on attenuated total reflection (ATR) combined with infrared spectroscopy, specifically ATR FT-IR, where infrared light is reflected from sample tissue using the ATR phenomenon to detect low signal glucose levels in a complex background. However, this approach struggles with sensitivity and interference from other biomolecules and from optical differences in tissues. To address these challenges, the research team implemented three key innovations: a multi-pass ATR reflections setup, quantum cascade laser (QCL) illumination, and advanced machine learning (ML) data analysis techniques (2).
Upgrading FT-IR for Superior Sensitivity
The first enhancement involved replacing the conventional single-pass ATR setup with a multiple-reflection ATR (MATR) configuration. This modification increased the signal-to-noise ratio by a factor of two to three, allowing for clearer glucose detection in complex biological tissue samples (2).
The second major enhancement replaced the traditional infrared lamp with a QCL, further tripling the signal-to-noise performance. The QCL, operating between 935 and 1128 cm⁻¹, precisely targeted glucose’s mid-infrared spectral signature, improving accuracy and reliability.
Leveraging Two-Dimensional Correlation Spectroscopy and AI
Beyond hardware improvements, the study leveraged two-dimensional correlation spectroscopy (2D-COS) to refine spectral analysis. Unlike traditional one-dimensional spectral methods, 2D-COS analyzes spectral variations across two wavelength axes, effectively minimizing interference from overlapping biomolecular signals (2).
To maximize analytical precision, the researchers also incorporated ML-based decision trees for hyperglycemia screening. They tested multiple algorithms, with a final approach combining three decision-tree models and a majority-voting mechanism. This strategy significantly improved classification performance, achieving an unprecedented 98.8% accuracy in distinguishing diabetic from non-diabetic glucose levels (2).
Extensive Testing and Validation
The study’s rigorous validation process involved 24 glucose concentrations (70–300 mg/dL) spanning both non-diabetic and diabetic ranges. Each concentration underwent 100 repeated spectral measurements, totaling 7,200 test spectra. The MATR-QCL-2D-COS combination yielded the best results, demonstrating not only high accuracy but also consistency across samples (2).
Implications for Diabetes Management
This research marks a notable step toward practical, non-invasive glucose monitoring solutions. By surpassing the accuracy benchmarks set by previous studies, including those requiring mechanical pressure for sampling, the upgraded FT-IR method could soon become a viable alternative to traditional blood-based glucose tests (2).
The integration of ML with advanced spectroscopic techniques opens new possibilities for rapid, painless, and highly accurate diabetes screening. As non-invasive technologies continue to advance, this breakthrough may pave the way for real-world applications in continuous glucose monitoring and early diabetes detection.
References
(1) National Institute of Diabetes and Digestive and Kidney Diseases (NIDDK) Diabetes Home Page. https://www.niddk.nih.gov/health-information/diabetes (accessed 2025-01-28)
(2) Song, L.; Han, Z.; Shum, P. W.; and Lau, W. M. Enhancing the Accuracy of Blood-Glucose Tests by Upgrading FTIR with Multiple-Reflections, Quantum Cascade Laser, Two-Dimensional Correlation Spectroscopy, and Machine Learning. Spectrochim. Acta A Mol. Biomol. Spectrosc. 2025, 327, 125400. DOI: 10.1016/j.saa.2024.125400
