Investigations of the interaction of small molecules with nucleic acids have been the focus of extensive research in recent years. The quantitative determination of nucleic acids is the basis of many studies. But direct use of the intrinsic fluorescence and ultraviolet absorption of nucleic acids for the determination has been severely limited by low sensitivity and serious interference (1–3).

Rayleigh scattering is a light-scattering phenomenon in which electromagnetic radiation and material act on each other and generate elastic collisions. According to the macroscopic fluctuation theory, the Rayleigh scattering law is obeyed (4) for the light scattering of the molecular particles 20-fold smaller than the wavelength of the incident beam. However, if the wavelength of the incident beam is close to that of the absorption band of the molecular particles, which exit as aggregates, Rayleigh scattering will deviate from the law and the intensity of some wavelengths will increase rapidly. This phenomenon is called resonance light scattering, or resonance-enhanced Rayleigh scattering, or resonance Rayleigh scattering (5). By using a common spectrofluorometer to measure the RLS, Pasternake and colleagues (6,7) studied the aggregations of porphyrins. Later, the RLS technique was used for determining nucleic acid and protein (8,9).

The probes for nucleic acids include cation porphyrins (6,10), triphenylmethane dyes (11,12), phenothiazinium dyes (13,14),  xanthene dyes, (15) metal complexes, (16,17) and nanoparticles (18,19). However, few investigations have been carried out to apply the anionic dyes as probe reagents to determine nucleic acids so far, due to the electrorepulsion between nucleic acids and anionic dyes.

By introducing the cationic surfactant CTMAB into the nucleic acids–anionic dyes system, we noticed that DNA, CTMAB, and anionic dyes can form a three-component complex, which results in enhanced RLS signals and can be applied successfully to determine DNA by the RLS method. At pH 6.75 and ionic strength 0.07, the anionic dye alizarin green (AG, Figure 1, displaying its molecular structure) can aggregate on the surface of DNA through the bridged and synergistic effect of CTMAB, which results in the enhanced

 of AG-CTMAB-yDNA system. The reaction mechanism and the influential factors on the variation of RLS have been investigated tentatively. This method enlarges the range of probe reagents of nucleic acids, which will be applied widely for quantitative determination of nucleic acids.

All reagents were of analytical reagent grade without further purification, and doubly distilled water was used throughout.

Stock solutions of nucleic acids were prepared by dissolving commercially purchased yeast DNA (Shanghai Changyan Pharmaceutical factory, Shanghai, China), calf thymus DNA (Shanghai Changyan Pharmaceutical factory), fish sperm DNA (fsDNA, Shanghai Institute of Biochemistry, Academy of Science, Shanghai, China), and yeast RNA (Shanghai Changyan Pharmaceutical factory) in doubly distilled water. These stocks needed to be stored at 0–4 °C with only an occasional gentle shake if needed. The concentration of DNA is determined according to the absorbance values at 260 nm by using ε

 , respectively (20). In this experiment, all working solutions of nucleic acids were 25.0 mg/L.

  mol/L stock solution of alizarin green (AG, Shanghai Chemical Reagents Co., Shanghai, China), was prepared by dissolving 0.3111 g of the crystal product in water in a 1000-mL volumetric flask.

  mol/L stock solution of cation surfactant cetyltrimethylammonium bromide (CTMAB, Merck, Germany), was prepared by dissolving 0.1832 g of the crystal product in water in a 1000-mL volumetric flask.

A 0.10-mol/L HMTA-HCl buffer solution was prepared by dissolving 0.1401 g hexamethylene tetramine (HMTA) in a 1000-mL volumetric flask in water, and adjusting the pH to 6.75 with HCl.

The RLS spectrum and the intensity of RLS were measured with an RF-5301PC (Shimadzu, Japan) fluorescence spectrometer by using a 1.00-cm quartz fluorescence cell. All absorption spectra were measured on a UV-265 spectrophotometer (Shimadzu, Japan). The surface tension (σ) was measured with a KrÜss KizMK5 programe surface tension instrument (Krss GmbH, Hamburg, Germany) by using the suspended plate method. A pHs-3C digital pH meter (Leici, Shanghai) was utilized to detect the pH values of the aqueous solutions.

Into a 25-mL volumetric test tube was added an appropriate volume of DNA solution according to the concentration needed, 0.50 mL 5.0 × 10

  mol/L AG, and 2.00 mL HMTA-HCl buffer. The mixture was diluted to the mark with water and mixed thoroughly, and was allowed to stand still for 10 min before RLS measurements. All measurements were made at an ambient temperature of 25 °C.

All RLS spectra were obtained by scanning the excitation and emission monochromators simultaneously (namely, Δλ = 0 nm) from 250.0 to 700.0 nm. The intensity of RLS was measured at λ = 340.0 nm in a quartz fluorescence cell with slit width at 3.0 nm for the excitation and emission. The enhanced intensity of the CTMAB-AG system by DNA was represented as Δ

 were the intensity of the system with and without DNA.

Features of the Resonance Light Scattering Spectrum

Figure 2 (curves 1–6) shows the light-scattering spectra of AG-CTMAB-yDNA-buffer, yDNA-CTMAB-buffer, AG-yDNA-buffer, AG-buffer, AG, and CTMAB-AG-buffer. It can be seen from the figure that their RLS intensities exhibit different features. In the whole scanning region, the RLS intensities of curve 2 and curve 3 are stronger than those of curve 6, but are still much weaker than those of curve 1, illustrating that the RLS of DNA is obviously enhanced with the help of both AG and CTMAB. Curve 4 and curve 5 are almost the same, which shows that the effect on the Δ

 values of adding HTMA to AG is weak. Similar RLS spectral characteristics can be surveyed when fsDNA, ctDNA, and RNA are used.

yDNA is a sort of surface-inactive anionic polyelectrolyte, and AG is also in the anionic state at pH 6.75. The electrorepulsion force between AG and DNA will prevent them from reacting with each other. CTMAB is a cationic surfactant; it can react with both AG and DNA due to electrostatic force to produce a kind of three-component complex (21) of AG-CTMAB-DNA at pH 6.75. The CTMAB in the system acts as a bridge between AG, and DNA and has a synergistic effect, which results in the greatly enhanced RLS intensities of DNA.

Because the enhanced extents of the RLS of AG-CTMAB-DNA system at 340.0 nm are in good proportion to the concentration of DNA, the 340.0 nm wavelength is selected for further research.

The effects of surfactant are examined and shown in Figure 3. Experiment results prove that different kinds of surfactants had different effects on Δ

, with CTMAB being the best surfactant. The effects of different buffers on Δ

 of AG-CTMAB-DNA system are investigated, and HMTA is the best buffer tested. The effects of CTMAB and pH are shown in Figure 4 and Figure 6, respectively. In Figure 4, Δ

 increases with increasing the concentration of CTMAB when it is below 7.5 × 10

  mol/L because CTMAB can form an ionic association complex with the phosphate groups of nucleic acids at appropriate concentration. Thus, the volume or size of nucleic acids acting as a template that AG assembles on is enlarged, which results in the enhanced Δ

 decreases when the concentration is above 3.0 × 10

   mol/L and is constant in the range 7.5 × 10

From the measurement of surface tension (Figure 5), we can obtain the critical associate concentration (CAC) in this system, which is 1.0 × 10

  mol/L CTMAB is selected for further research. Figure 6 shows that the enhancement of light scattering changes a lot and reaches a maximum with pH in the range 6.00 to 7.00. The dependence of light scattering upon pH might be relevant to the form of AG and DNA; when pH is below 6.00, both the free base form of AG and DNA are protonized, which is not favorable for positively charged CTMAB to be close to the DNA molecule. At the same time, the concentration of AG with two negative charges is low, which is not favorable for the reaction of AG and CTMAB. When the pH is above 7.00, the Δ

 of AG markedly decreases. So pH 6.75 is chosen for further research.

The effect of alizarin green concentration on Δ

 of the AG-CTMAB-DNA system is investigated and shown in Figure 7. When the concentration of alizarin green is in the range 8.0 × 10

 of the AG-CTMAB-DNA system reaches a maximum. So we select 1.0 × 10

Effect of Addition Order of the Reagents

It is very important that the addition order of reagents be fixed. Our experiments show the optimal addition order of the reagents to be as follows: DNA should be mixed with CTMAB first, and then AG and the buffer can be added in. When AG, CTMAB, DNA, and buffer are added successively, the Δ

 of the system is much smaller (6). The study of the interaction mechanism of nucleic acids-CTMAB with AG shows that changing the order of reagents can alter the initial concentrations of DNA. When CTMAB reacts with DNA first, this is favorable for the aggregation of AG on the surface of the DNA molecule.

 of the AG-CTMAB-DNA system is shown in Figure 8. The Δ

 of the AG-CTMAB-DNA system lessens markedly with the increasing ionic strength, showing that electrostatic makes a key contribution to the interaction of CTMAB, DNA, and AG. Hydrophobic force probably does its work in the creation of the three-component complex of AG-CTMAB-DNA.

The complex of AG-CTMAB-DNA is sensitive to ionic strength of medium, and Δ

 decreases with the increasing ionic strength due to the weakening combination of the complex but changes slightly when the ionic strength is below 0.07 mol/L. So to get the best Δ

 in this work, ionic strength must be controlled to be below 0.07 mol/L.

The binding reaction of DNA and AG with CTMAB is completed after 10 min. They are mixed together at room temperature (25 °C); Δ

 remains a constant for about 3 h. The reaction has good stability.

Tolerance of Foreign Coexisting Substances

The effect of substances including metal ions, amino acids, galactose, and adenine are examined for interference. The results are summarized in Table I. Most of the metal ions in biological systems, such as K

 , can be tolerated at high concentrations.
