 are terms that are often used interchangeably when discussing the characteristics of materials. Nevertheless, their meanings are different.

 is a force per unit area applied to an object, and

 is the effect on the object from the stress. Specifically,

 is the change in the positions of the atoms or the lengths of the chemical bonds within the object that are induced by the application of stress. Here, we discuss the distinction of these terms, and their mathematical forms as applied to crystals. Strain is manifest in Raman spectra through changes in peak position and bandwidth. We present examples of the identification of strain in crystals of several technologically important materials.

 have often read how stress or strain can be detected by Raman spectroscopy through the shifting or broadening of certain bands. In this installment of "Molecular Spectroscopy Workbench," we delve more deeply into this topic, discussing the physics and mathematics of stress and strain, and demonstrating their effects on Raman spectra. We begin by carefully defining these two terms, and making the proper distinction between them. Readers interested in a deeper mathematical explanation of stress and strain are encouraged to read the two chapters on these subjects in the classic work by Nye (1).

	When external forces are applied to an object that does not move, we say that it is under

. Furthermore, if the forces on the object do not vary spatially, then the object is subject to

. Stress normally occurs over an area of an object, and not just a point location. Therefore, stress is properly understood as the force per unit area applied to an object, and is described mathematically by the second rank tensor shown in equation 1, where

	We may consider an ideal object such as a cube with the usual

axes to better understand the components of the stress tensor. The stress forces applied along the cube's

-axis are said to be the normal components of stress, and are associated with the tensor elements

, respectively. These normal component forces can be applied inward, directed towards the center of the object, or outward. The former is defined as a

. The sign convention that has been adopted is that a positive value of

 corresponds to a tensile stress, whereas a negative value indicates a compressive stress. Now, it is important to understand and appreciate that the stress forces applied to opposite faces of our ideal cube must be of equal magnitude, but from opposite directions, for our cube to not move. That is why we can describe stress as a static force. The magnitudes of the stress forces need not be the same on the

 faces, but they must be the same on the opposite pair of faces.

 of stress, whereas all of the other off-diagonal tensor elements such as

. The shear tensor elements are paired under a condition of static equilibrium such that

 would be shear forces perpendicular to the normal component

. In summary, the stress tensor diagonal elements describe the force per unit area as compressive or tensile normal components, and the off-diagonal tensor elements describe the shear unit area forces.

	We have thus far discussed the stress tensor with respect to an ideal cubic object. We can now take those principles and begin to apply them to crystals of real chemical compounds or elements, and understand the strain induced in the crystal as a result of the application of the stress. It is critically important to understand how stress and strain differ.

 is the change of the positions of the atoms, or the lengths of the chemical bonds within a crystal that are induced by the application of stress. Thus, for a cubic crystal such as silicon (Si), we can expect that a stress of a given magnitude applied along a crystallographic axis will produce the same degree of strain, whether it is applied along the

 crystallographic axis. However, for a uniaxial or biaxial crystal where all three crystallographic axes are not identical, the amount of strain induced by a given magnitude of stress will depend on the chemical bonding and forces along a particular crystal axis. Therefore, it is actually the changes in atomic positions and chemical bond lengths commensurate with strain that are detected in the Raman spectrum through the changes in peak position or band broadening.

	The relationship between a homogeneous stress and homogeneous strain as a generalized form of Hooke's Law is given by

 is the elastic compliance constant of the crystalline material. The strain tensor is a second rank 3 x 3 tensor of the same form as the stress tensor shown in equation 1. Therefore, equation 4 consists of nine equations, each with nine components on the right hand side. For example,

	Of course, there will be eight similar equations for the remaining

 tensor elements. The implication of equations 3 and 4 is that, if even only one component of the stress is nonzero,

 for example, all of the strain elements may be nonzero. Consider what that last statement could mean applied to a rectangular or even cubic crystal. If a uniaxial stress is applied to one face of the crystal, it will stretch in the direction of the applied force, but may also undergo shearing such that the angles between faces may differ from the original 90 degrees. In other words, strain may be induced in a material in a direction other than that of the applied stress.

	We have discussed compressive and tensile stress, and so we can now understand the compressive and tensile strain induced in a crystal or material as a result of the application of the corresponding stress forces. If a crystal is subjected to a tensile stress, we can envision the atoms being pulled apart, or chemical bonds lengthened, relative to their normal positions and lengths in an unstressed crystal. As the chemical bond length increases, and the force constant remains the same, we should expect the vibrational frequency to decrease. A shift of the Raman peak position to lower frequencies is exactly what is observed from materials that have been subjected to a tensile stress. Conversely, if a compressive stress is applied, we would expect the atoms in a crystal to move closer together, or the chemical bond lengths to be shortened, relative to their normal positions and lengths in an unstressed crystal. The resulting compressive strain in the crystal results in Raman peak positions shifted to higher frequencies. The lesson to be learned here is that compressive and tensile stresses will induce corresponding strains in the crystal that can be observed as shifts of a Raman peak position to higher or lower frequencies, respectively. The magnitude of the Raman peak shift will be commensurate with that of the stress and corresponding strain induced in the material. The degree to which the Raman band will shift is dependent on the specific material under examination and the elastic compliance constant (

) of that chemical compound or element, and the specific crystallographic axes being probed.

	As you can see, the stress–strain tensor relationship in even the most simple crystal structures can be complex. Nevertheless, quantitative analysis of stress or strain by Raman spectroscopy has been performed on a variety of materials, including silicon (2–7), aluminum oxide (8–10), barium titanate (11–12), and aluminum nitride (13). Now that we have reviewed the fundamental physics of stress and strain, we can examine how they affect the Raman spectra in various technologically important materials.

	Much of the early work on microRaman spectroscopy of semiconductors involved the characterization of polycrystalline silicon (14–17), also known as polysilicon, which is still used extensively in fabricated electronic devices. Theoretical and experimental work was directed towards an understanding of how strain, microcrystallinity, and crystal lattice defects or disorder can all affect the Raman band shape, position, and scattering strength of single and polycrystalline silicon (18–20). The presence of nanocrystalline silicon in polysilicon was confirmed through the combination of transmission electron microscopy and Raman spectroscopy, and the effects of extremely small silicon grain dimensions on the Raman spectra were attributed to phonon confinement (21–24). As the crystalline grain size becomes smaller, comparable to the wavelength of the incident laser light or less, the Raman band broadens and shifts relative to that obtained from a crystalline domain significantly larger than the excitation wavelength. This has been explained in part by phonon confinement, in which the location of the phonon becomes more certain as the grain size becomes smaller, and therefore the energy of the phonon measured must become less certain consistent with the Heisenberg uncertainty principle.

	It is important to understand the effects of nanocrystallinity on the Raman spectrum, so as not to wrongly attribute the spectral features of nanocrystals to strain in microcrystalline or larger grain sizes. Of course, strain can be present in nanocrystalline materials. If that is the case, then one will not be able to strictly differentiate the combined effects of strain and nanocrystallinity on the Raman spectrum.

	A collection of data from a polysilicon test structure is shown in Figure 1. A reflected white light image of the structure appears in the lower right hand corner, and a Raman image corresponding to the central structure in the reflected light image appears to its left. The plot on the upper left consists of all of the Raman spectra acquired over the image area and the upper right hand plot is of the single spectrum associated with the cursor location in the Raman and reflected light images. The Raman data were acquired using 532 nm excitation and a 100x Olympus objective and by moving the stage in 200 nm increments over an approximate area of 25 µm × 25 µm. In this particular case, the Raman image is rendered through a color coded plot of Raman signal strength of the corresponding color bracketed Raman shift positions in the two upper traces.


	Figure 1: (a) Raman hyperspectral data set from a polysilicon test structure with (d) white reflected light image in lower right corner; (b) a Raman image generated from the spatially varying signal strengths between the color coded brackets in the spectral traces; (c) the single spectrum corresponding to the cross hairs in the Raman and white reflected light images.

	Raman spectra of the unstrained substrate silicon, microcrystalline and strained polycrystalline silicon, and nanocrystalline silicon are shown in Figure 2. The substrate silicon spectrum consists of the Raman band at 521 cm

 arising from the first order optical phonon at the Brillouin zone center. The Raman band in the spectrum of microcrystalline polysilicon appears at 515 cm

 relative to the peak position of the unstrained substrate silicon, thereby indicating the presence of tensile strain. The increased width of the polysilicon silicon Raman band indicates that there is a distribution of strains, and the band shift is not the result of a single uniaxial stress. The shoulder at 521 cm

 can be attributed to the substrate silicon underlying the polycrystalline silicon film. The spectrum of nanocrystalline silicon manifests substantial broadening with the peak centered at 502 cm

. As a result, the substrate silicon signal at 521 cm

 is now better resolved. The substantial broadening and peak center shift of approximately –19 cm

 are consistent with phonon confinement associated with crystal grain sizes with nanometer dimensions. Of course, the nanocrystalline silicon can also be strained, but the effects of strain cannot be differentiated from those of nanocrystallinity in the Raman spectrum.


	Figure 2: Raman spectra of the substrate silicon (red), microcrystalline and strained polycrystalline silicon (green), and nanocrystalline silicon (blue).

	With respect to our explanation of the Raman spectra in Figure 2, we now discuss the reasoning behind our choice of the color-coded brackets to render the Raman image, and how they relate to differences in the solid-state structure of silicon. If we were to have a merely elemental compositional image of this particular structure, we would expect it to be entirely uniform without spatial variation, because silicon would appear in every pixel of the image. However, if we distinguish the different solid-state structures of the silicon by identifying unstrained silicon with the Brillouin zone center Raman band of 520.7 cm

 isolated in red brackets, microcrystalline and strained polycrystalline silicon in green brackets, and a distribution of nanocrystallinity and strain in the blue brackets, we can render the Raman image in the lower left hand corner. To some degree strain, microcrystallinity, and nanocrystallinity are comingled in the polysilicon regions of our images; however, we can make a reasonable distinction by attributing the blue regions as primarily due to nanocrystalline grain size.

	Now we consider what our rendering reveals in the Raman image, expanded for more detailed examination in Figure 3. The red regions consist of either substrate silicon or grown single crystal silicon with different oxide thicknesses. The spatial variation of the single crystal Raman signal strengths corresponds precisely with the physical optical effects of the oxide thicknesses and even small contaminants or defects seen in the reflected light image. Furthermore, because of the thinness of the polysilicon A alone, one can see through the green polysilicon A component to the underlying red substrate silicon, particularly on the left and right of the upper and lower portions of Figure 3. The spatial variation of the microcrystalline and strained polycrystalline silicon green component signal strength corresponds to both the central strip consisting of polysilicon B deposited on polysilicon A and the granular variation of polysilicon A seen in the reflected light image. Note that the polysilicon A bright green speckles in the Raman image correspond precisely to black speckles in the reflected light image. Careful examination of the central strip reveals these same speckles in the polysilicon A blurred somewhat by the polysilicon B deposited on top of it.


	Figure 3: The Raman image from Figure 1b. Red corresponds to single crystal silicon, green to microcrystalline and strained polysilicon, and blue to nanocrystalline silicon. Polysilicon B (in the center) was deposited on the wider, underlying polysilicon A.

	Now let's turn our attention to the appearance of nanocrystalline silicon in the image. The formation of nanocrystalline silicon occurs almost exclusively in polysilicon A and only on top of the central single crystal silicon structure, and not the substrate silicon. Note that the nanocrystallinity occurs primarily along the edge of the polysilicon A, but is absent as the polysilicon A continues along the silicon substrate. Also, we see that some of the polysilicon A speckles appear blue, thereby revealing nanocrystallinity over the central structure but not over the silicon substrate.

	In summary, the intensity variations of the single crystal silicon comport with the physical optical effects of varying oxide film thickness and surface contaminants. Also, this Raman image reveals the spatially varying nanocrystallinity, microcrystallinity and strain in polysilicon. We can infer that these structural differences occur either as a result of processing conditions, or from interactions with the adjacent or underlying materials in which the polysilicon is in contact. The use of narrow colored brackets with our hyperspectral mapping data set allows one to differentiate strain free, strained microcrystalline, and nanocrystalline silicon and to render an image of these spatially varying solid state structures.

	The fabrication of diamond films by chemical vapor deposition (CVD) has been under development for many years now for applications including hardened surfaces, optical windows, and electrodes. The solid-state structure of these films has a direct impact on the material properties and therefore figures of merit of the final product. Crystallinity, single or poly, the number of defects, strain, and even crystal face, can affect performance. Furthermore, the uniformity of such films can affect the overall utility of the final product. Therefore, analytical methods are called for that can characterize the spatially varying structure of CVD diamond films.

	To that end, we have made use of Raman polarization selection rules for the purpose of simply differentiating single from polycrystalline diamond, and to probe the extent of lattice defects, spatially varying strain, and the degree of disorder present in a crystal. We have applied polarization-orientation (P-O) Raman spectroscopy to characterize diamond films for crystallinity and strain. The reader is referred to a previous publication on P-O Raman spectroscopy to understand the theory and practical applications of this method (25).

	The CVD films consisted of diamond clusters whose edge lengths ranged from approximately 5 µm to 15 µm. The faces of the diamonds are square and triangular and presumably correspond to the (100) and (111) faces, respectively. We performed P-O Raman spectroscopy on the isolated square faces for the characterization of CVD diamond crystallinity. A reflected light image of one such square face from which P-O microRaman spectra were obtained is shown in Figure 4.


	Figure 4: Reflected white light image of diamond prepared by chemical vapor deposition from which P-O microRaman spectra were obtained.

	We obtained P-O Raman spectra of diamond films prepared by chemical vapor deposition using a 1.6 mW, 488.0 nm laser beam focused to a 0.6 µm diameter with an Olympus MS Plan 100 (0.95 NA) objective. Raman scattered light was collected using the same microscope objective (backscattering configuration). An analyzer was placed in front of the spectrometer entrance slit, and configured either parallel or perpendicular to the incident polarization. Individual spectra were collected at 5° rotational increments for each analyzer polarization configuration as the sample is then rotated within the focal plane. The sensitivities of the microscope and spectrometer to the two, orthogonal polarizations were characterized against a depolarized white light source. Accordingly, corrections were made to the intensities of P-O Raman spectra obtained at the corresponding polarizations.

	The P-O Raman spectra shown in Figure 5 indicate that the diamond is a single crystal that contains substantial defects. The orientational dependence of the Raman spectra manifest the expected sinusoidal response for a single crystal diamond rotated in a (100) plane with the parallel and perpendicular P-O spectral plots 45° out of phase with each other. However, the failure of the signal to vanish at the minima and the presence of an amorphous carbon band at approximately 1560 cm

 invariant with orientation reveal considerable defects in what is nominally a single crystal of diamond.


	Figure 5: P-O Raman spectra of a (100) face of the CVD diamond shown in Figure 4. The light collection analyzer was oriented (a) parallel and (b) perpendicular to the incident polarization.

	In addition to the defect-induced disorder manifest in the spectra, crystal orientation dependent strain can be identified through band fitting. The strain-free Raman band of diamond appears at 1333 cm

. Previous work by other authors has demonstrated the crystallographic orientational variation of strain in diamond films and the use of polarized Raman spectroscopy to detect it (26-28). Figure 6 shows two Raman spectra from the perpendicular polarization set (Figure 5) separated by 5 rotational degrees. Band fitting reveals a strain-free component at 1333 cm

, thereby indicating the presence of compressive strain. Note that the relative contributions of the strain-free to strained components of the diamond Raman band are inverted, even though the crystal has been rotated by only 5°. Indeed, the 3D variation of the strain in this crystal contributes significantly to the deviation of the experimentally obtained P-O diagram from one calculated for an ideal crystal. Were the diamond to be free of defects and spatially varying strain, we would expect the Raman signal strengths to be zero at the minima in the P-O plots shown in Figure 5.


	Figure 6: P-O Raman spectra separated by 5 rotational degrees for (a) versus (b). The spectra are fitted for strain-free diamond (~1333 cm

Strain in Two-Dimensional Molybdenum Disulfide

	There is a great need for characterization of two-dimensional (2D) transition metal dichalcogenide crystals because of their experimental nature and structural variability, often within one film. We have discussed the resonance Raman and photoluminescence spectroscopy and imaging of few-layer molybdenum disulfide previously (29). The spatial variation of the number of atomic layers of 2D crystals can often be inferred from the hue or color of the crystal when viewed using reflected white light microscopy, and so there have been developments to use optical microscopy to rapidly identify the number of stoichiometric layers that make up the 2D crystal (30). However, spatially varying strain in 2D crystals does not manifest itself in reflected white light images. In this article, we focus on spatially varying strain in exfoliated and chemical vapor deposition molybdenum disulfide revealed by Raman spectroscopy.

	Several spectra and a Raman image of a large exfoliated molybdenum disulfide few-layer flake, and a smaller flake nearby, are shown in Figure 7. The Raman data were acquired using 532 nm excitation and a 100x Olympus objective and by moving the stage in 300 nm increments. The Raman image is a rendering of signal strength for a particular Raman band as a function of position on the sample. In this case, the Raman image is rendered through red corresponding to the Raman band of substrate silicon at 521 cm

, and green is associated with the Raman signal of the molybdenum disulfide A


	Figure 7: Raman spectra of few-layer molybdendum disulfide from different locations on the two flakes shown in the inset Raman image. The spectrum from the center is not strained. Note the substantial shifts and broadening corresponding to strain in the perimeter and flake spectra.

	Most of the large flake is strain free; however, substantial tensile strain is present along a portion of the perimeter. Raman spectroscopy is most useful for identifying spatially varying and heterogeneous strain through the broadening and shifting of bands relative to those from areas free of strain. Here, the broadening and the shifting to lower wavenumber by 4 cm

 bands indicate the presence of tensile strain in the small flake and at the perimeter of the large flake. An interesting observation is that, very often, the structure of the perimeter of a few-layer molybdenum disulfide flake is quite different from that of the interior manifesting differences in both Raman scattering and photoluminescence.

	Strain is frequently observed at the perimeters of exfoliated molybdenum disulfide few-layer flakes. It can also be detected at the perimeters and interfaces of 2D crystals grown by chemical vapor deposition. A collection of hyperspectral data and the corresponding Raman image from primarily single-layer molybdenum disulfide crystals grown on a silicon substrate are shown in Figure 8. The Raman data were acquired using 532 nm excitation and a 50x Olympus objective and by moving the stage in 1 µm increments over an area of approximately 120 µm × 90 µm. The spectra consist primarily of the E

) molybdenum disulfide bands, and the first order optical phonon from silicon at 521 cm

. A reflected white light image of the sample area appears in the lower right hand corner, and a Raman image corresponding to the reflected light image appears to its left. The large triangular features in the white light image are single-layer molybdenum disulfide crystals, and the surrounding lighter area is the silicon substrate. The small dark area at the center of the upper triangle is two-layer molybdenum disulfide. The plot on the upper left consists of all of the Raman spectra acquired over the image area. The upper right hand plot is of the single spectrum associated with the cross hair location in the Raman and reflected light images; the line cursor is positioned at the E

 peak of strain-free molybdenum disulfide to reveal the strain at the cross hair location. The presence of shear E

) bands in the hyperspectral data set (upper left of Figure 8) from the small dark area confirms that it is two-layer molybdenum disulfide (31). These low frequency bands are absent in the spectra of single-layer molybdenum disulfide.


	Figure 8: (a) Raman hyperspectral data set from molybdendum disulfide grown on silicon with (d) white reflected light image in lower right corner. (b) Raman image generated from the spatially varying signal strengths between the red brackets in the hyperspectral plot. (c) The single spectrum corresponding to the cross hairs in the Raman and white reflected light images; the line cursor is positioned at the E

	The red Raman image in the lower left of Figure 8 corresponds to the E

) molybdenum disulfide band between the red brackets seen in the plot in the upper left. The Raman image is a rendering of signal strength between the brackets as a function of position on the sample. In this particular case, the red brackets have been made narrow, and placed around the E

) band as it appears in the interior of the crystal away from both the perimeter and crystal interfaces. Narrowing the brackets allows them to function as a spectral slit in the image generation; Raman bands that shift to lower or higher frequency will manifest decreased intensity as less of the band will appear between the narrow brackets. Consequently, areas of strain will show diminished signal strength and appear darker in the Raman image, because the Raman band has shifted to either lower or higher frequency depending on whether the strain is tensile or compressive, respectively.

	We need to carefully examine the spectra from the Raman map in Figure 8 to understand how the narrow brackets function as a spectral slit to reveal strain and even the two-layer molybdenum disulfide in the Raman image. Representative spectra of the interior single-layer molybdenum disulfide, perimeter, strained crystal interface, and dark two-layer molybdenum disulfide are shown in Figure 9. The Raman spectrum of the interior single-layer molybdenum disulfide free of strain consists of the E

 (402.1 cm-1) bands. The Raman spectrum of the dark two-layer molybdenum disulfide consists of the E

, respectively, relative to those of the single-layer molybdenum disulfide. The increased separation of the E

 bands, along with the aforementioned presence of the low frequency bands, confirms that the small dark area in the upper triangle is two-layer molybdenum disulfide. The E

) bands in the spectrum of the perimeter have shifted to -0.2 cm

, respectively, thereby indicating the presence of a tensile strain at the perimeter. The E

) bands in the spectrum of the strained crystal interface (the dark areas between the crystals) have shifted to +1.3 cm

, respectively, thereby indicating the presence of a compressive strain. The E

 band and so the selection to bracket the E

 band makes it a better choice for revealing spatially varying strain at the crystal interfaces in the Raman image.


	Figure 9: Raman spectra obtained from different locations of sample shown in Figure 8: Interior single-layer molybdendum disulfide (red), perimeter (green), strained crystal interface (blue), and dark two-layer molybdendum disulfide (brown).

	Now we consider what our rendering reveals in the Raman image expanded for more detailed examination in Figure 10. We choose a single spectral component color image with spectrally narrow brackets to reveal the spatially varying strain associated with the chosen Raman band. In this particular case, the red brackets have been made narrow, and placed around the E

) band as it appears in the interior of the crystal away from both the perimeter and crystal interface. Using a narrow bracket allows it to function as a spectral slit in the image generation, thereby differentiating the strain-free single-layer molybdenum disulfide from the strained areas, as well as the two-layer molybdenum disulfide. As explained above, areas of strain appear darker in the Raman image because the band has shifted and contributes less signal strength within the narrow spectral brackets. The spectra in Figure 9 revealed the compressive strain at the interfaces of the triangular molybdenum disulfide crystals where the E

. Consequently, the Raman image of the adjoining single-layer molybdenum disulfide crystals appears darkest precisely at the interfaces where the crystals met upon their individual growth. Note that the darkness at the interfaces projects diffusely for micrometers into the crystal, thereby revealing the projection of spatially varying and diminishing strain at some distance from the interface into the interior of the crystal. Of course, the spatially varying strain seen in the Raman image is not detected in the reflected white light image. Raman imaging has revealed a distribution of strain in the crystals that could not have been known based upon the appearance of the reflected white light image.


	Figure 10: The Raman image from Figure 8b. Red corresponds to the narrow bracketed E

. The interfacial areas appear dark because the E

 band has shifted to higher wavenumber due to compressive stress.

	Another collection of hyperspectral data and the corresponding Raman image of single-layer, two-layer and three-layer molybdenum disulfide crystals grown on a silicon substrate are shown in Figure 11. The triangle in the center of the reflected white light image (lower right) consists of spatially varying two-layer, and three-layer molybdenum disulfide, the pink circle surrounding the triangle is single-layer molybdenum disulfide, and the area outside of the circle is the bare silicon substrate. The red Raman image in the lower left of Figure 11 corresponds to the spatially varying signal strength of the E

) molybdenum disulfide band between the red brackets seen in the spectral plots. The plot on the upper right is of the single spectrum associated with the cross hair location at the interface of the multilayer triangle and single-layer molybdenum disulfide; note the splitting of the A


	Figure 11: (a) Raman hyperspectral data set from molybdendum disulfide grown on silicon with (d) white reflected light image in lower right corner. The Raman image (b) was generated from the spatially varying signal strengths between the red brackets in the spectral plots. (c) The single spectrum corresponds to the cross hairs in the Raman and white reflected light images.

	We examine the spectra from the Raman map in Figure 11 to understand the basis for the contrast between the single-layer molybdenum disulfide and the spatially varying two- and three-layer molybdenum disulfide triangle and the bright interface around the multilayer molybdenum disulfide triangle in the Raman image. Representative spectra of the single-layer molybdenum disulfide, triangle and single-layer molybdenum disulfide interface, and three-layer molybdenum disulfide are shown in Figure 12. The Raman spectrum of the single-layer molybdenum disulfide free of strain consists of the E

) bands. The Raman spectrum of the triangular three-layer molybdenum disulfide consists of the E

) bands relative to the separation of the two-layer molybdenum disulfide in Figure 9 (–1.7 cm

) confirms that the area of the triangle from which this spectrum was generated is three-layer molybdenum disulfide. Further support for this interpretation is how much broader the E

 bands in the spectrum of three-layer molybdenum disulfide are relative to their counterparts in the two-layer molybdenum disulfide spectrum. The shift of the E

 band to lower wavenumber away from the narrow brackets centered at 382.1 cm

 is the basis for the diminished signal strength and dark appearance of the spatially varying two-layer and three-layer molybdenum disulfide triangle.


	Figure 12: Raman spectra obtained from different locations of sample shown in Figure 11: Surrounding single-layer molybdendum disulfide (red), triangle and single-layer molybdendum disulfide interface (blue), and three-layer molybdendum disulfide (green).

	The interface of the spatially varying two-layer and three-layer molybdenum disulfide triangle adjoining the single layer molybdenum disulfide presents a structurally different case from the crystal interface of the single-layer molybdenum disulfide crystals that have grown to meet each other. Here, we see a splitting of the A

) bands in the spectrum of the triangle and single-layer molybdenum disulfide interface have shifted to –0.6 cm

) which is very different from either the perimeter or strained crystal interface spectra in Figure 9. The spectral interpretation at this interface is not as straightforward, because of the convolution of the multilayer and single layer molybdenum disulfide signals within the same spectrum. We may interpret the E

) bands at the crystalline interface as consistent with a transition from the single-layer to two-layer molybdenum disulfide. However, the second A

, relative to the single-layer molybdenum disulfide A

) band, thereby indicating a compressive strain at the interface.

	The symmetry species and the directions of the atomic motions of the phonon modes affected by stress can help us to understand the differences observed in the images and spectra of Figures 8–12. The E

 band is associated with vibrations along the

-axis (31). Therefore, these bands will be sensitive to strain in orthogonal directions in the crystal, the doubly degenerate E

-axis (32–33). The large shift of +4.3 cm

 band in the spectrum of the triangle multilayer–single-layer molybdenum disulfide interface is indicative of a significant compressive strain along the

-axis, whereas there is no indication of strain in the

-plane based upon the peak position of the E

 band. This is quite different from the interfaces created by the growth of single-layer molybdenum disulfide crystals meeting each other. In the case of the contiguous single-layer molybdenum disulfide crystals, the E

 bands in the spectrum of the strained crystal interface (the dark area between the crystals) have shifted by as much as +1.3 cm

, respectively, thereby indicating the presence of a compressive strain in the

 axis. In contrast, a compressive strain of far greater magnitude appears only along the

-axis at the triangle multilayer–single-layer molybdenum disulfide interface.

	Stress and strain were defined, and a mathematical description of their relationship was provided, making the proper distinction between the two terms.

is a force per unit area applied to an object, and

 is the change in the positions of the atoms, or the lengths of the chemical bonds within the object that are induced by the application of stress. Compressive and tensile stresses will induce corresponding strains in the crystal, which can be observed as shifts of a Raman peak position to higher or lower frequencies, respectively. The magnitude of the Raman peak shift will be commensurate with that of the stress and corresponding strain induced in the material. The degree to which the Raman band will shift is dependent upon the specific material under examination, the elastic compliance constant (

	Raman spectroscopy is sensitive to strain, and has therefore been successfully used for the characterization of strain in materials. Raman spectra of the unstrained substrate silicon, microcrystalline and strained polycrystalline silicon, and nanocrystalline silicon from a silicon device test structure were presented and formed the basis of a Raman image. The Raman image of the test structure revealed the spatially varying nanocrystallinity, microcrystallinity and strain in polysilicon. Strain was also identified in diamond films prepared by chemical vapor deposition. We have applied polarization-orientation Raman spectroscopy to characterize diamond films for crystallinity and strain. Band fitting reveals a strain-free component at 1333 cm

, thereby indicating the presence of compressive strain.

	Lastly, we discussed spatially varying strain in exfoliated and chemical vapor deposition molybdenum disulfide revealed by Raman spectroscopy. Most of the exfoliated flake is strain free; however, substantial tensile strain is present along a portion of the perimeter. Raman spectroscopy is useful for identifying spatially varying and heterogeneous strain in exfoliated molybdenum disulfide through the broadening and shifting of bands relative to those from areas free of strain. Strain was also detected at the perimeters and interfaces of 2D crystals grown by chemical vapor deposition. The Raman image of adjoining single-layer molybdenum disulfide crystals revealed strain at the interfaces where the crystals met upon their individual growth. The strain projects diffusely for micrometers into the crystal. The strain is greatest at the crystal interface and spatially varies and diminishes at some distance from the interface into the interior of the crystal. Here, the E

 bands in the spectrum of the strained crystal interface have shifted by as much as +1.3 cm

-axis. The spatially varying strain seen in the Raman image is not detected in the reflected white light image. Contrast was observed in a second Raman image between the single-layer molybdenum disulfide and the spatially varying two- and three-layer molybdenum disulfide triangle and the bright interface around the multi-layer molybdenum disulfide triangle. We interpret the E

) band, thereby indicating a compressive strain at the interface. Compressive strain appears only along the

-axis at the triangle multilayer–single-layer molybdenum disulfide interface. This is quite different from the interface created by the growth of single-layer molybdenum disulfide crystals meeting each other.

(Oxford University Press, 1985), pp. 82-109.

	(2) G.H. Loechelt, N.G. Cave and J. Menendez,

	(3) G.H. Loechelt, N.G. Cave, and J. Menendez,

	(4) I. De Wolf, H. Norstrom, and H.E. Maes,

	(5) S.C. Jain, H.E. Maes, K. Pinardi, and I. De Wolf,

	(11) G. Pezzotti, M. Higashino, K. Tsuji, and W. Zhu,

	(14) Y. Inoue, S. Nakashima, A. Mitsuishi, T. Nishimura, and Y. Akasaka,

	(15) D. R. Tallant, T. J. Headley, J. W. Medernach, and F. Geyling,

	(17) G. Harbeke, L. Krausbauer, E. F. Steigmeier, A. E. Widmer, H. F. Kappert, and G. Neugebauer,

	(18) G.-X. Cheng, H. Xia, K.-J. Chen, W. Zhang and X.-K. Zhang,

	(20) H. Richter, Z. P. Wang, and L. Ley,

Molecular Spectroscopy Workbench

When stress is applied to an object, it can produce strain. Strain can be detected through changes in peak position and bandwidth in Raman spectra. Here, we show examples of how strain in technologically important materials appears in
the Raman spectra.

Stress, Strain, and Raman Spectroscopy

Analysis of 47 FDA Form 483 observations and warning letters for infrared spectrometers reveals a spectrum of data integrity problems and a lack of laboratory procedures for the technique. Is this your laboratory?

	Since the Able Laboratories data falsification case in 2005 (1), there has been a regulatory focus on the lack of data integrity with chromatography data systems. This scrutiny has focused on inappropriate access privileges with conflicts of interest, deletion of data files, failure to configure the application, testing into compliance, and failure to review audit trail entries (2). More recently, inspection focus has moved to the use of peak integration to integrate into compliance and masking potential impurities (3). There have been many warning letters as a result of these noncompliances and poor data management practices; this is due to chromatography being a major technique that can comprise between 40–70% of a laboratory's workload. You may ask, "Why the focus on chromatography in a publication on spectroscopy?" Just think of chromatography as sample preparation for spectroscopy!

	In contrast, there are relatively few FDA warning letters involving spectroscopic techniques. An analysis of FDA warning letters citing infrared spectrometers was published in 2014 (4).

	Originally, we were going to write a column looking at some of the data integrity issues that could occur with Fourier transform infrared spectroscopy (FT-IR) analysis, with a few regulatory citations to illustrate each point. However, given the bonanza of Form 483 observations and warning letters that have been issued by the FDA, we realized that an analysis of these would provide a great overview of the current regulatory problems facing the technique, before discussing specific topics in the future.

	In this column, we present an analysis of 47 Form 483 observations and warning letters issued between 2012 and 2018 (5–51). It should be noted that many of these Form 483 observations are not generally available publicly. Therefore, these observations, the regulatory focus on infrared, and the conclusions we have drawn may be new to laboratories that only review FDA warning letters. We have taken each citation or observation and broken it down into one or more data integrity areas; therefore, a single observation can have one or more data integrity noncompliances. For example:

		The application does not have an audit trail. This is a single 483 observation and a single data integrity issue.

		In contrast, here is a more complex citation: System audit trails are not available on the two FT-IR instruments, and quality control (QC) operators have the option of not saving the IR data. This citation will be classified into two entries; one of no audit trail, and another of application software design because data are not automatically saved. This is a simple example of compound data integrity problems, but some citations can be far more detailed and complex.

	Therefore, there is not a one-to-one correlation between all non-compliances analyzed and the data classification presented here.

	The noncompliances have resulted in a total of 104 separate citations for IR analysis that have been classified and discussed below. Some of these are self-explanatory, and will not be discussed in part due to space considerations and because the solution is obvious (such as no software validation, for example). In the references, we have included the FDA Facility Establishment Identifier (FEI), which is the way the FDA identifies a specific site in a company. Where there are different FEI numbers for the same organization, this means that two sites or facilities were inspected.

	Our main challenge in this analysis is to interpret a regulatory citation, because we don't know all the circumstances at the time of the observation by an inspector. For example, we don't know the functionality of the application software, so the observation of no system audit trails available as shown above could be a true software design limitation, or, more likely, it could be that the users did not enable this function. We have used our experience and best judgement in classifying each citation in this analysis.

	We do not claim that this noncompliance review reflects the total number of 483 observations issued, but, based on the significant number, it is reasonably comprehensive to draw firm conclusions on regulatory gaps involving IR analysis. Enjoy reading about the calamities of others. If any noncompliance mentioned here applies to your laboratory, what are you going to do? We suggest that you remediate the problem before you are included in a future update of this article!

Citations Before the Operational Use of the Instrument

	One of the surprises of our analysis is that 42% of the 483 citations occur before the instrument and the associated software application are supposed to become operational. You may doubt this statement, but look at both Table I and Figure 1 and you will see two main areas: inadequate software architecture, and design and failure to qualify, calibrate, or validate the system. The interpretation of these nonconformance data is based on the wording of the 483 observations.

	The biggest area, at 37% of the total noncompliances, appears to be due to inadequate architecture and design of the application software that has been purchased by the regulated laboratories. The main problems with the application software are that, as implemented, there are inadequate controls for ensuring data integrity, no audit trail, and the architecture where data files are stored in directories within the operating system and users can delete data without any record in the data system. Again, this is based on the wording inspectors included in each Form 483 report, which represents a high level conclusive summary of the inspection findings, and not a detailed analysis of the root cause associated with each observation. In particular, this represents the inspector's interpretation of what was found about how software was implemented, and not the full compliance capabilities of each software package. In line with FDA warning letters, in many instances, the manufacturer and name of the software was included in many of the examples we reviewed, but we have redacted these in this column.


	Figure 1: Infrared spectroscopy Form 483 citations occurring before operational use of the instrument and software.

	Some of the citations for poor software design are:

		The UV and FT-IR analytical instruments are both equipped with commercial software that does not prevent accidental or intentional deletion of files containing data.

		QC operators have the option of not saving the IR spectra.

		With the FT-IR instrument (QC/FT-IR/201), it was noted that the redacted software had an option to enable or disable automatic saving of measurement available to the chemist.

		FT-IR spectrophotometers used in identity testing were observed to have a "delete" option available to the user.

		The lack of an audit trail was one of the largest number of citations; there was no audit trail in 16 out of 104, or 15%, of all citations.

	The use of directories in the operating system for data storage where a user can delete spectral files without any record in the application software (assuming there is a function capable of this) gave rise to 17 citations out of 104, or 16%.

		There were no controls to prevent deletion of data and deleted FT-IR data was observed in the computer recycle bin.

		Data can be deleted off the FT-IR used in the testing of active pharmaceutical ingredient (API). The data can be deleted off the computer systems hard drive, outside of the system software, and therefore not captured by the systems audit trail.

		Laboratory personnel can change and save changes to the date and time setting in the Windows operating system.

	The first problem is that regulated laboratories are purchasing IR application software that appears not to have any or inadequate data integrity controls. For example, all data should be saved, and there must be an audit trail built into the system which, once implemented, cannot be turned off. However, suppliers are market driven, and if users don't ask for these features, or help into how to implement them, then they won't be delivered. The responsibility of the supplier to help customers implement a compliant solution is becoming increasingly important. There is also the overall market that a supplier is developing its software for both regulated and unregulated industry sectors. What should occur is that suppliers should be selling configurable software, and also providing assistance in the form of white papers informing users how to configure the software or providing professional services to help implement compliant solutions. The second issue is the overall architecture of the system: Almost all IR software is designed for standalone operation, or can be implemented as a standalone system. Many standalone systems involve files storage in directories in an operating system, and not a database. If the software is designed to support networked implementation, using database storage on a secure network server, this should be implemented. This would remove many of the limitations of standalone systems, such as backup, as this would be performed by the IT department.

	Part of the problem is that many software applications require a range of expertise to implement compliant solutions, so that an expert in the analytical technique, someone with a detailed understanding of the software capabilities and strong IT and Part 11 knowledge, is required. From the number of Form 483 observations, it is clear that this multidisciplinary collaboration has not occurred.

What are Performance Qualification Tests for IR Instruments?

	The second area for noncompliance before operational use of the instrument (6%) is due to failure to qualify or calibrate the instrument or validate the software. This is a fairly straightforward area, and we were not going to discuss this, with the exception of two citations about the performance qualification of an IR instrument, one of which is:

	No Performance Qualification (PQ) is required before use to ensure the performance of the <redacted> FT-IR; only the . . . operation qualification is performed. In addition, the SOP # <redacted> does not require such a test.

(USP) general chapter <1058> on Analytical Instrument Qualification (AIQ) was recently updated (52), and contains new requirements compared with the 2008 version. The key issues are that:

		Users must write a user requirements specification (URS) that contains the operating parameters for the IR spectrometer and the instrument software.

		These parameters are verified in the Operational Qualification (OQ).

		Performance Qualification (PQ) needs tests that either directly or indirectly confirm that the instrument continues to operate in compliance with the operating parameters in the URS (52).

	The difference between an instrument OQ and PQ is typically the area of greatest discussion when considering analytical instrument qualification. It is important to first understand that, because an OQ and PQ test different attributes of instrument performance, both are required.

	Uniquely for FT-IR, the subject of calibration also needs to be considered because of confusion that can arise around interpretation of this word. First, in simple terms, the instrument performance attributes that are associated with an OQ and PQ are:

		OQ: Documents how the instrument satisfies user requirements before operational release and at regular intervals, typically after an annual preventative maintenance service.

		PQ: Demonstrates the instrument continues to work under actual conditions of use as documented in the user requirements specification.

	The reader must consider what these terms mean for an FT-IR instrument, and be able to defend this interpretation during regulatory inspections.

	For an FT-IR instrument, apart from replacing the internal desiccant that removes water vapor from sealed instrument enclosure, there are typically no user serviceable components. Therefore, it would be more appropriate to label regular testing of instrument as performance verification checks for wavelength accuracy, resolution, and signal-to-noise, rather than calibration. However, for an FDA inspector, calibration is most likely to be the name used for instrument performance checks, because this is specified in the Good Manufacturing Practice regulations in 21

	Tests performed on analytical instruments during qualification typically fall under the following categories:

		metrology-based tests (not needed for an FT-IR instrument, unless temperature controlled)

	We will return to this topic in a later "Focus on Quality" column, where we will address OQ and PQ requirements for FT-IR in more detail.

	The main citations for IR systems found by FDA inspectors during the operational phase are listed in Table II, and shown diagrammatically in Figure 2. In general, these citations mirror those found with chromatography data systems (CDS) such as:


	Figure 2: Infrared spectroscopy Form 483 observations as found by FDA inspectors during operational work.

		Poor Security and Access Control: This is the biggest problem with issues identified such as no security, all users have the same identity, and password thus making attribution of action impossible and conflicts of interest where all laboratory users have administrator rights. Some people will never learn! This is especially true when these citations against CDS have been made for the past 10–15 years. What is interesting in this case is that some laboratories have been cited because management had administrator access, confirming a requirement for application administration to be independent of the laboratory.

		Data Falsification/Testing into Compliance: This is another classic area for citations that is not limited to CDS, and are also found with IR systems. Citations here include data deletion, and retesting until a passing result is obtained. Some people never learn.

		No Audit Trail Review: Even when you have an audit trail in the application, it is ether turned off or if it is turned on the entries are not reviewed. There is even one citation where the audit trail is stored on a secure network, but the laboratory and QA staff cannot access it!

		Failure to Backup Data: This is a major problem when a laboratory is left to backup its own GMP records, and fails to do so. It is always better to get the IT department to back the data up on secure network drives.

	In addition, there are the following gems of noncompliance:

		Work Not Scientifically Sound: A variety of novel and unscientific approaches to charm FDA inspectors, such as use of IR analysis for cleaning validation where lack of sensitivity to detect an analyte was the issue (for example, using an identification algorithm to compare spectra of cleaning wash samples with pure solvents). On the bright side, every cleaning validation passes.

Analysis of FDA Form 483 observations and warning letters for infrared spectrometers reveals a range of data integrity problems and a lack of laboratory procedures for the technique. Is your laboratory in the same situation?

Spectroscopy-09-01-2019

Vol 34 No 9 Spectroscopy September 2019 Regular Issue PDF

Stress, Strain, and Raman Spectroscopy

Analysis of FDA Infrared 483 Citations: Have You a Data Integrity Problem?

Organic Nitrogen Compounds V: Amine Salts

Combined Raman Spectroscopy and Rheology for Characterizing

High Voltage Accuracy and Precision on Small Compact X-ray Sources

Microwave Digestion and Trace Metals Analysis of Cannabis and Hemp Products

Analysis of Organic Chlorides in Crude by ASTM D4929 PART C

Trace-Level Pesticide Detection Utilizing Surface-Enhanced Raman Spectroscopy (SERS)

Observation of Methanol in Ethanol Using Automated ATR Spectroscopy

Microparticles in Focus
